General Purpose Solid Carbide End Mills • Roughing/Finishing
Series 423039 423038 • NINA™
• Centre cutting.
• Standard items listed. Additional styles
and coatings made-to-order.
Series 423039 423038 • NINA
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance h10
+/-
D
0/0,04
)3
0/0,048
> 3–6
0/0,058
> 6–10
0/0,070
> 10–18
0/0,084
> 18–30
tolerance h6
+/-
0/0,006
0/0,008
0/0,009
0/0,011
0/0,013
first choice
alternate choice
gradKe30KF3-0DFC-HCPHP
TiAlN
order # catalogue #
graKde30KF3-0DFC-HDPCHP
TiAlN
order # catalogue #
length of cut
length
D1 D
Ap1 max
L
2343531 423039-000020
2343514 423038-000020
2,0
6
4,00
38
2343533 423039-000030
2343516 423038-000030
3,0
6
5,00
38
2343535 423039-000040
2343519 423038-000040
4,0
6
7,00
38
2343537 423039-000050
2343521 423038-000050
5,0
6
8,00
38
2343539 423039-000060
2343523 423038-000060
6,0
6
8,00
38
2343541 423039-000080
2343525 423038-000080
8,0
8
11,00
43
2343543 423039-000100 2343527 423038-000100 10,0 10
13,00
50
2343545 423039-000120 2343529 423038-000120 12,0 12
15,00
55
NOTE: For application data, please see page P10.
