General Purpose Solid Carbide End Mills • Roughing/Finishing
Series 423036 423037 • NINA™
• Non-centre cutting.
• Chamfering.
• Standard items listed. Additional styles
and coatings made-to-order.
Series 423036 423037 • NINA
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance h10
+/-
D
0/0,04
)3
0/0,048
> 3–6
0/0,058
> 6–10
0/0,070
> 10–18
0/0,084
> 18–30
tolerance h6
+/-
0/0,006
0/0,008
0/0,009
0/0,011
0/0,013
first choice
alternate choice
graKde30KF3-0DFC-FDCF
TiAlN
order # catalogue #
graKde30KF3-0DFC-HDPCHP
AlTiN
order # catalogue #
length of cut
length
D1 D
Ap1 max
L
2343508 423036-000060
—
6,0 6
1,00
38
—
2628498 423037-000060
6,0
6
1,00
83
2343510 423036-000080
—
8,0 8
1,50
43
—
2628499 423037-000080
8,0
8
1,50
104
2343512 423036-000100
—
10,0 10
2,00
50
—
2628500 423037-000100 10,0 10
2,00
125
NOTE: For application data, please see page P11.
P8
