General Purpose Solid Carbide End Mills • Roughing/Finishing
Series 2819 • VariMill™ GP
• Centre cutting.
• Chamfered corners.
• Standard items listed. Additional styles
and coatings made-to-order.
Detail X
Series 2819 • VariMill GP
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance e8
-0,014/-0,028
-0,020/-0,038
-0,025/-0,047
-0,032/-0,059
-0,040/-0,073
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/0,006
0/0,008
0/0,009
0/0,011
0/0,013
first choice
alternate choice
grUaNdeCOUNATCEODAT- E..D
order # catalogue #
graTdieATlNiAlN
TiAlN
order # catalogue #
length of cut
length
D1 D
Ap1 max
L BCH
5877617 28190300T007
5877603 28190300T007
3,0
3
8,00
50 —
5877618 28190400T008
5877604 28190400T008
4,0
4
8,00
50 0,10
5877619 28190500T010
5877605 28190500T010
5,0
5
10,00
50 0,10
5877620 28190600T010
5877606 28190600T010
6,0
6
10,00
57 0,10
5877621 28190700T013
5877607 28190700T013
7,0
7
13,00
60 0,10
5877622 28190800T016
5877608 28190800T016
8,0
8
16,00
63 0,20
5877623 28190900T016
5877609 28190900T016
9,0
9
16,00
67 0,20
5877624 28191000T019 5877610 28191000T019 10,0 10
19,00
72 0,20
5877625 28191200T022 5877611 28191200T022 12,0 12
22,00
83 0,30
5877626 28191400T022 5877612 28191400T022 14,0 14
22,00
83 0,30
5877627 28191500T026 5877613 28191500T026 15,0 15
26,00
92 0,30
5877628 28191600T026 5877614 28191600T026 16,0 16
26,00
92 0,30
5877629 28191800T026 5877615 28191800T026 18,0 18
26,00
92 0,30
5877630 28192000T032 5877616 28192000T032 20,0 20
32,00
104 0,30
NOTE: For application data, please see page P23.
