General Purpose Solid Carbide End Mills • Roughing/Finishing
Series 4002 4012 • VariMill™ GP
• Centre cutting.
• Chamfered corners.
• Standard items listed. Additional styles
and coatings made-to-order.
Detail X
Series 4002 4012 • VariMill GP
graTdieATlNiAlN
TiAlN
order #
5873484
5873485
5873486
5873487
5873488
5873489
5873490
5873491
5873492
5873493
5873494
5873495
5873496
5873497
5873498
5873499
5873500
5873501
5873502
5873503
catalogue #
40020100T004
40020150T004
40020180T004
40020200T006
40020250T006
40020300T009
40020300T019
40120300T025
40020350T012
40020400T012
40020400T019
40120400T031
40020450T014
40020480T014
40020500T014
40020500T020
40120500T031
40020550T014
40020600T016
40020600T028
D1
1,0
1,5
1,8
2,0
2,5
3,0
3,0
3,0
3,5
4,0
4,0
4,0
4,5
4,8
5,0
5,0
5,0
5,5
6,0
6,0
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance e8
-0,014/-0,028
-0,020/-0,038
-0,025/-0,047
-0,032/-0,059
-0,040/-0,073
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/0,006
0/0,008
0/0,009
0/0,011
0/0,013
first choice
alternate choice
length of cut
length
D Ap1 max
L BCH
3 4,00
38 —
3 4,00
38 —
3 4,00
38 —
3 6,30
38 —
3 6,30
38 —
3 9,50
38 —
3 19,00
63 —
3 25,00
75 —
4 12,00
50 —
4 12,00
50 0,10
4 19,00
63 0,10
4 31,00
75 0,10
6 14,00
50 0,10
6 14,00
50 0,10
5 14,00
50 0,10
5 20,00
63 0,10
5 31,00
100 0,10
6 14,00
50 0,10
6 16,00
50 0,10
6 28,00
76 0,10
(continued)
