Hole Finishing
ROTAFLEX™ High-Performance Boring Systems
Application Hints • Micro-Adjustable Cartridges
Axial adjustment wedge
1mm adjustment range
Fastening screw
Lubrication nipple
Lithium saponified hydroxide is the recommended
grease. The maintenance interval depends on the
operating conditions. In permanent operations, a
regreasing is recommended every four weeks.
Micro adjustment
0,01mm diameter adjustment.
Radial adjustment range of 0,6mm.
Rotation speed max 10,000 RPM
Application Hints • RFX Coupling
Old RFX screw-type coupling can be mounted into new RFX bayonet-type adaptors as well.
Old RFX —
Torque flats needed
to disassemble.
Old RFX —
Cylinder and thread.
NEW RFX —
Bayonet type of coupling,
with axial preload for stability.
Thread —
Able to assemble
old RFX as well.
NEW RFX – Adaptors
Two radial screws clamp,
preload the coupling, and enable
rotation in both directions.
