High-Performance Taps
Victory™ Left-Hand Spiral-Flute HSS-E-PM Taps • Through Holes
• GM6515 TiN + CrC/C for
stainless steel.
• GP6520 TiCN for steel.
Shank Tolerance
D mm
tolerance h6
>3–6 +0, -0,008
>6–10
+0, -0,009
>10–18
+0, -0,011
>18–30
+0, -0,013
>30–50
+0, -0,016
GT21 • Form D Plug Chamfer • Through Coolant • Metric DIN 371 and 376 • For Steel and Stainless Steel
first choice
alternate choice
gradGeP6G5P260520
TiCN
order # catalogue #
3955054 GT215007
3955055 GT215008
3955056 GT215009
3955057 GT215010
3955058 GT215011
3955059 GT215012
gradGeMG6M5165515
TiN+CrC/C
order # catalogue #
3955038 GT215001
3955039 GT215002
3955040 GT215003
3955041 GT215004
3955042 GT215005
3955053 GT215006
D1 size
M5 X 0,8
M6 X 1
M8 X 1,25
M10 X 1,5
M12 X 1,75
M14 X 2
metric dimensions
L L3 L2 D
70 10 25 6,0
80 10 30 6,0
90 13 35 8,0
100 15 39 10,0
110 18 44
9,0
110 20 52 11,0
number
of utes
2
3
3
3
3
4
dimension
standard
DIN 371
DIN 371
DIN 371
DIN 371
DIN 376
DIN 376
class
of t
6HX
6HX
6HX
6HX
6HX
6HX
Y6
