WIDIA - Полный каталог инструмента - 2017
• WN48EG DLC for aluminium.
для размещения заказа - zakaz@widiahanita.ru
High-Performance Taps
Victory™ Spiral-Point Plug HSS-E-PM Taps • Through Holes
GT70 • Form B Plug Chamfer • Metric DIN 371 and 376 • For Aluminium
Shank Tolerance
D mm
tolerance h9
1–3 +0, -0,025
3,5–6
+0, -0,030
7–10 +0, -0,036
11–18
+0, -0,043
first choice
alternate choice
graWdeNW48NE4G8EG
DLC
order # catalogue #
4160036 GT705001
4160037 GT705002
4160038 GT705003
4160039 GT705004
4160040 GT705005
4160041 GT705006
4160042 GT705007
4160063 GT705008
D1 size
M3 X 0,5
M4 X 0,7
M5 X 0,8
M6 X 1
M8 X 1,25
M10 X 1,5
M12 X 1,75
M16 X 2
metric dimensions
L L3 L2 D
56 11 18 3,5
63 13 21 4,5
70 15 25 6,0
80 17 30 6,0
90 20 35 8,0
100 22 39 10,0
110 24 — 9,0
110 27 — 12,0
number
of utes
2
2
2
2
2
2
3
3
dimension
standard
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 376
DIN 376
class
of t
6H
6H
6H
6H
6H
6H
6H
6H
zakaz@widiahanita.ru
www.widiahanita.ru
Y9
