High-Performance Taps
Victory™ Spiral-Flute HSS-E-PM Taps • Blind Holes
• GP6520 TiCN for steel
and cast iron.
Shank Tolerance
D mm
tolerance h6
12–18
+0, -0,011
20–30
+0, -0,013
32–36
+0, -0,016
GT50 • Form C Semi-Bottoming Chamfer • Larger Sizes • Metric DIN 376 • For Steel and Cast Iron
first choice
alternate choice
graGdeP6G5P260520
TiCN
order # catalogue #
4154254 GT505001
4154255 GT505002
4154256 GT505003
4154257 GT505004
4154258 GT505005
D1 size
metric dimensions
number
dimension
class
L L3 L2
D
of utes
standard
of t
M24 X 3 160 30 77 18,0
4
DIN 376
6HX
M30 X 3,5 180 35 91 22,0
5
DIN 376
6HX
M33 X 3,5 180 35 100 25,0
5
DIN 376
6HX
M36 X 4
200 40 110 28,0
5
DIN 376
6HX
M42 X 4,5 200 45 120 32,0
6
DIN 376
6HX
Y26
