• WP31MG TiN
for steel 32–44 HRC.
для размещения заказа - zakaz@widiahanita.ru
High-Performance Taps
Victory™ Spiral-Flute HSS-E-PM Taps • Blind Holes
Shank Tolerance
D mm
tolerance h9
1–3 +0, -0,025
>3–6
+0, -0,030
>6–10
+0, -0,036
>10–18
+0, -0,043
>18–30
+0, -0,052
GT02 • Form C Semi-Bottoming Chamfer • Metric DIN 371, 374, and 376 • For Hard Steel
first choice
alternate choice
graWdePW31PM3G1MG
TiN
order # catalogue #
4152638 GT025001
4152639 GT025002
4152640 GT025003
4152641 GT025004
4152709 GT025012
4152642 GT025005
4152710 GT025013
4152711 GT025014
4152703 GT025006
4152712 GT025015
4152713 GT025016
4152704 GT025007
4152714 GT025017
4152705 GT025008
4152715 GT025018
4152706 GT025009
4152707 GT025010
4152708 GT025011
D1 size
M3 X 0,5
M4 X 0,7
M5 X 0,8
M6 X 1
M8 X 1
M8 X 1,25
M10 X 1
M10 X 1,25
M10 X 1,5
M12 X 1,25
M12 X 1,5
M12 X 1,75
M14 X 1,5
M14 X 2
M16 X 1,5
M16 X 2
M18 X 2
M20 X 2,5
metric dimensions
L L3 L2 D
56 11 18 3,5
63 13 21 4,5
70 15 25 6,0
80 17 30 6,0
90 17 — 6,0
90 20 35 8,0
90 18 — 7,0
100 22 — 7,0
100 22 39 10,0
100 22 — 9,0
100 22 — 9,0
110 24 44 12,0
100 22 — 11,0
110 26 52 11,0
100 22 — 12,0
110 27 — 12,0
125 30 — 14,0
140 32 — 16,0
number
of utes
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
4
4
dimension
standard
DIN 371
DIN 371
DIN 371
DIN 371
DIN 374
DIN 371
DIN 374
DIN 374
DIN 371
DIN 374
DIN 374
DIN 376
DIN 374
DIN 376
DIN 374
DIN 376
DIN 376
DIN 376
class
of t
6H
6H
6H
6H
6H
6H
6H
6H
6H
6H
6H
6H
6H
6H
6H
6H
6H
6H
