High-Performance Taps

Victory™ Spiral-Flute HSS-E-PM Taps • Blind Holes 3 x D

• WH36MG TiAlN/MoS2 for steel

32–44 HRC (3 x D).

Shank Tolerance

D mm

tolerance h9

1–3 +0, -0,025

>3–6 +0, -0,030

>6–10

+0, -0,036

>10–18

+0, -0,043

>18–30

+0, -0,052

GT04 • Form C Semi-Bottoming Chamfer • Metric DIN 371, 374, and 376 • For Hard Steel

first choice

alternate choice

graWdeHW36HM3G6MG

TiN+MoS2

order # catalogue #

4158471 GT045001

4158472 GT045002

4158763 GT045003

4158764 GT045004

4158772 GT045012

4158765 GT045005

4158773 GT045013

4158774 GT045014

4158766 GT045006

4158775 GT045015

4158776 GT045016

4158767 GT045007

4158777 GT045017

4158768 GT045008

4158778 GT045018

4158769 GT045009

4158770 GT045010

4158771 GT045011

D1 size

M3 X 0,5

M4 X 0,7

M5 X 0,8

M6 X 1

M8 X 1

M8 X 1,25

M10 X 1

M10 X 1,25

M10 X 1,5

M12 X 1,25

M12 X 1,5

M12 X 1,75

M14 X 1,5

M14 X 2

M16 X 1,5

M16 X 2

M18 X 2,5

M20 X 2,5

metric dimensions

L L3 L2 D

56 6 18 3,5

63 7 21 4,5

70 8 25 6,0

80 10 30 6,0

90 10 — 6,0

90 14 35 8,0

90 10 — 7,0

100 16 —

7,0

100 16 39 10,0

100 15 —

9,0

100 15 —

9,0

110 18 —

9,0

100 15 — 11,0

110 20 — 11,0

100 15 — 12,0

110 22 — 12,0

125 25 — 14,0

140 25 — 16,0

number

of utes

dimension

standard

DIN 371

DIN 374

DIN 371

DIN 374

DIN 371

DIN 374

DIN 376

DIN 374

DIN 376

DIN 374

DIN 376

class

of t

Y34
