Multipurpose Taps
VariTap™ Spiral-Flute HSS-E Taps • Blind Holes
Shank Tolerance
D mm
tolerance h9
1–3 +0, -0,025
>3–6
+0, -0,030
>6–10
+0, -0,036
>10–18
+0, -0,043
>18–30
+0, -0,052
VT-SFT • Form C Semi-Bottoming Chamfer • Machine Screw and Fractional • DIN 371 and 376
first choice
alternate choice
graWdeUW41UE4G1EG
TiN
order # catalogue #
5472587 VTSFT6005
5472589 VTSFT6007
5472600 VTSFT6008
5472602 VTSFT6010
5472603 VTSFT6011
5472605 VTSFT6013
5472606 VTSFT6014
5472608 VTSFT6016
5472609 VTSFT6017
5472611 VTSFT6019
5472612 VTSFT6020
5472614 VTSFT6022
5472615 VTSFT6023
5472617 VTSFT6025
5472618 VTSFT6026
5472620 VTSFT6028
5472621 VTSFT6029
5472623 VTSFT6031
5472624 VTSFT6032
5472625 VTSFT6033
graWdePW49PE4G9EG
Oxide
order # catalogue #
5387487 VTSFT6005
5387489 VTSFT6007
5387640 VTSFT6008
5387642 VTSFT6010
5387643 VTSFT6011
5387645 VTSFT6013
5387646 VTSFT6014
5387648 VTSFT6016
5387649 VTSFT6017
5387651 VTSFT6019
5387652 VTSFT6020
5387654 VTSFT6022
5387655 VTSFT6023
5387657 VTSFT6025
5387658 VTSFT6026
5387670 VTSFT6028
5387671 VTSFT6029
5387673 VTSFT6031
5387674 VTSFT6032
5387675 VTSFT6033
D1 size
4 - 40
5 - 40
6 - 32
6 - 40
8 - 32
10 - 24
10 - 32
1/4 - 20
1/4 - 28
5/16 - 18
5/16 - 24
3/8 - 16
3/8 - 24
7/16 - 14
7/16 - 20
1/2 - 13
1/2 - 20
9/16 - 12
9/16 - 18
5/8 - 11
metric dimensions
L L3 L2 D
56 8 18 3,5
56 9 20 4,0
56 9 20 4,0
56 9 20 4,0
63 11 21 4,5
70 12 25 6,0
70 12 25 6,0
80 15 30 7,0
80 15 30 7,0
90 15 35 8,0
90 15 35 8,0
100 19 39 10,0
100 19 39 10,0
100 18 41
8,0
100 18 41
8,0
110 23 40
9,0
110 23 40
9,0
110 25 32 11,0
110 25 32 11,0
110 24 35 12,0
number
of utes
2
2
2
2
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
dimension
standard
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 376
DIN 376
DIN 376
DIN 376
DIN 376
DIN 376
DIN 376
class
of t
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
2B
(continued)
