WIDIA - Полный каталог инструмента - 2017
• GP6520 TiCN for cast iron
and cast aluminium.
для размещения заказа - zakaz@widiahanita.ru
High-Performance Taps
Victory™ Straight-Flute HSS-E-PM Taps • Through and Blind Holes
Shank Tolerance
D mm
tolerance h6
>3–6
+0, -0,008
>6–10
+0, -0,009
>10–18
+0, -0,011
>18–30
+0, -0,013
>30–50
+0, -0,016
GT41 • Form C Semi-Bottoming Chamfer • Through Coolant • Metric DIN 371, 374, and 376 • For Cast Iron
and Cast Aluminium
first choice
alternate choice
graGdeP6G5P260520
TiCN
order # catalogue #
4033659 GT415001
4033660 GT415002
4033661 GT415003
4033662 GT415004
4033813 GT415005
5408069 GT415021
4033814 GT415006
5408400 GT415022
4033815 GT415007
5408401 GT415023
4033816 GT415008
4033817 GT415009
4033818 GT415010
D1 size
M4 X 0,7
M5 X 0,8
M6 X 1
M8 X 1,25
M10 X 1,5
M12 X 1,5
M12 X 1,75
M14 X 1,5
M14 X 2
M16 X 1,5
M16 X 2
M18 X 2,5
M20 X 2,5
metric dimensions
L L3 L2 D
63 10 21 4,5
70 10 25 6,0
80 10 30 6,0
90 13 35 8,0
100 15 39 10,0
100 15 39 9,0
110 18 44 9,0
100 15 47 11,0
110 20 52 11,0
100 15 46 12,0
110 20 51 12,0
125 25 58 14,0
140 25 64 16,0
number
of utes
3
3
4
4
4
4
4
4
4
4
4
4
4
dimension
standard
DIN 371
DIN 371
DIN 371
DIN 371
DIN 371
DIN 374
DIN 376
DIN 374
DIN 376
DIN 374
DIN 376
DIN 376
DIN 376
class
of t
6HX
6HX
6HX
6HX
6HX
6HX
6HX
6HX
6HX
6HX
6HX
6HX
6HX
