High-Performance Thread Mills
Victory™ Solid Carbide Thread Mills • Blind and Through Holes
GTM11 • Through Coolant • Metric and Metric Fine
Shank Tolerance
D mm
tolerance h6
6 +0, -0,008
8–10 +0, -0,009
12–18
+0, -0,011
20–30
+0, -0,013
first choice
alternate choice
gradWeUW13UP1V3PV
TiAlN
order # catalogue #
4138391 GTM115001
4138502 GTM115012
4138392 GTM115002
4138503 GTM115013
4138493 GTM115003
4138504 GTM115014
4138494 GTM115004
4138505 GTM115015
4138506 GTM115016
4138495 GTM115005
4138507 GTM115017
4138496 GTM115006
4138508 GTM115018
4138509 GTM115019
4138497 GTM115007
4138510 GTM115020
4138498 GTM115008
4138511 GTM115021
4138499 GTM115009
4138512 GTM115022
4138500 GTM115010
4138513 GTM115023
4138501 GTM115011
D1 size
M3X0.5
M4X0.5
M4X0.7
M5X0.5
M5X0.8
M6X0.75
M6X1
M8X0.75
M8X1
M8X1.25
M10X1
M10X1.5
M12X1
M12X1.5
M12X1.75
M14X1.5
M14X2
M16X1.5
M16X2
M18X1.5
M18X2.5
M20X1.5
M20X2.5
D1
2,4
3,4
3,2
4,3
4,0
5,0
4,8
5,9
5,9
5,9
7,9
7,9
9,9
9,9
9,9
9,9
11,6
11,9
11,9
13,9
13,9
13,9
13,9
metric dimensions
Ap1 max
6
8
9
10
11
12
12
17
16
17
20
20
24
25
25
29
29
32
33
37
39
41
41
L
42
55
55
55
55
55
55
63
63
63
70
70
80
80
80
80
90
90
90
90
90
90
90
LS
28
36
36
36
36
36
36
36
36
36
36
36
40
40
40
40
45
45
45
45
45
45
45
D
4,0
6,0
6,0
6,0
6,0
6,0
6,0
6,0
6,0
6,0
8,0
8,0
10,0
10,0
10,0
10,0
12,0
12,0
12,0
14,0
14,0
14,0
14,0
cutting
edges
3
3
3
3
3
3
3
3
3
3
3
3
4
4
4
4
4
4
4
4
4
4
4
