High-Performance Thread Mills
Victory™ Solid Carbide Thread Mills • Blind and Through Holes
GTM21 • Through Coolant • Inch UNC and UNF
Shank Tolerance
D mm
tolerance h6
6 +0, -0,008
8–10 +0, -0,009
12–18
+0, -0,011
20–30
+0, -0,013
first choice
alternate choice
gradWeUW12UP1V2PV
TiCN
order # catalogue #
4138537 GTM215024
4138530 GTM215017
4138538 GTM215025
4138531 GTM215018
4138539 GTM215026
4138532 GTM215019
4138540 GTM215027
4138533 GTM215020
4138541 GTM215028
4138534 GTM215021
4138542 GTM215029
4138535 GTM215022
4138543 GTM215030
4138536 GTM215023
4138544 GTM215031
D1 TPI
#10-32
1/4-20
1/4-28
5/16-18
5/16-24
3/8-16
3/8-24
7/16-14
7/16-20
1/2-13
1/2-20
9/16-12
9/16-18
5/8-11
5/8-18
D1
3,8
4,7
5,2
6,2
6,6
7,7
8,2
9,0
9,6
10,4
11,1
11,8
12,5
13,1
14,1
DCH
5,13
6,65
6,65
8,25
8,25
9,83
9,83
11,43
11,43
13,00
13,00
14,61
14,61
16,18
16,18
metric dimensions
LTHD
9,95
13,36
13,19
16,26
16,44
19,89
19,62
22,72
22,28
26,43
26,10
30,75
28,99
33,54
33,24
LDCH
10,53
14,23
13,84
17,19
17,15
20,85
20,31
23,79
23,08
27,60
26,89
31,99
29,88
34,89
34,09
L
55
62
62
74
74
80
80
80
80
90
90
100
100
102
102
LS D
36 6,0
36 8,0
36 8,0
40 10,0
40 10,0
45 12,0
45 12,0
45 12,0
45 12,0
45 14,0
45 14,0
48 16,0
48 16,0
48 18,0
48 18,0
cutting
edges
3
3
3
3
3
3
3
3
3
4
4
4
4
4
4
Y70
