High-Performance Thread Mills
Victory™ Solid Carbide Thread Mills • Blind and Through Holes
GTM21 • Through Coolant • Metric and Metric Fine
Shank Tolerance
D mm
tolerance h6
6 +0, -0,008
8–10 +0, -0,009
12–18
+0, -0,011
20–30
+0, -0,013
first choice
alternate choice
gradWeUW12UP1V2PV
TiCN
order # catalogue #
4138514 GTM215001
4138521 GTM215008
4138515 GTM215002
4138522 GTM215009
4138516 GTM215003
4138523 GTM215010
4138524 GTM215011
4138517 GTM215004
4138525 GTM215012
4138526 GTM215013
4138527 GTM215014
4138518 GTM215005
4138528 GTM215015
4138519 GTM215006
4138529 GTM215016
4138520 GTM215007
metric dimensions
cutting
D1 size
D1
DCH
LTHD
LDCH
L
LS
D
edges
M5X0.8
4,0
5,30
10,82
11,40
55 36 6,0
3
M6X0.75
5,0
6,30
12,40
12,97
62 36 8,0
3
M6X1
4,8
6,30
12,52
13,19
62 36 8,0
3
M8X1
6,7
8,30
16,53
17,23
74
40 10,0
3
M8X1.25
6,5
8,30
16,91
17,71
74
40 10,0
3
M10X1
8,7
10,30
20,55
21,23
80
45 12,0
3
M10X1.25
8,4
10,30
20,67
21,50
80
45 12,0
3
M10X1.5 8,2 10,30 20,29 21,22 80 45 12,0
3
M12X1
10,6 12,30
24,56
25,27
90 45 14,0
4
M12X1.25 10,4 12,30
24,43
25,24
90
45 14,0
4
M12X1.5
10,1 12,30
24,80
25,76
90
45 14,0
4
M12X1.75 9,9 12,30 25,42 26,48 90 45 14,0
4
M14X1.5
12,1 14,30
29,31
30,25
100 48 16,0
4
M14X2
11,6 14,30
29,05
30,24
100 48 16,0
4
M16X1.5
14,0 16,30
32,31
33,30
102 48 18,0
4
M16X2
13,6 16,30
33,05
34,24
102 48 18,0
4
