High-Performance Thread Mills
Victory™ Solid Carbide Thread Mills • Blind and Through Holes
GTM31 • Through Coolant • Inch UNC and UNF
Shank Tolerance
D mm
tolerance h6
6 +0, -0,008
8–10 +0, -0,009
12–18
+0, -0,011
20–30
+0, -0,013
first choice
alternate choice
gradWeUW12UP1V2PV
TiCN
metric dimensions
cutting
order # catalogue #
D1 TPI
D1
D22
DCH
LTHD
LDCH
L
LS
D
edges
4138561 GTM315021
1/4-20
4,9
5,2
6,65
12,80
15,87
62 36 8,0
2
4138568 GTM315028
1/4-28
5,3
5,5
6,65
12,79
15,35
62 36 8,0
2
4138562 GTM315023
5/16-18
6,3
6,6
8,25
15,63
19,19
74 40 10,0
2
4138569 GTM315030
5/16-24
6,6
6,9
8,25
15,98
19,07
74 40 10,0
2
4138563 GTM315017w
3/8-16
7,7
8,0
9,83
19,16
23,25
79 45 12,0
2
4138570 GTM315024
3/8-24
8,2
8,5
9,83
19,16
22,54
79
45 12,0
2
4138564 GTM315018
7/16-14
9,0
9,4 11,43 21,89 26,58
79 45 12,0
2
4138571 GTM315025
7/16-20
9,6
9,9 11,43 21,72 25,69
79
45 12,0
2
4138565 GTM315019
1/2-13
10,4 10,8 13,00
25,52
30,71
89
45 14,0
2
4138572 GTM315026
1/2-20 11,1 11,5 13,00 25,55 29,82 89 45 14,0
2
4138566 GTM315020
9/16-12 11,8 12,3 14,61 27,66
33,37 102 48 16,0
2
4138573 GTM315027
9/16-18 12,5 12,9 14,61 28,37
33,15 102 48 16,0
2
4138567 GTM315022
5/8-11
13,1 13,5 16,18 30,14
36,40
102 48 18,0
2
4138574 GTM315029
5/8-18
14,1 14,5 16,18 31,21
36,25
102 48 18,0
2
Y72
