High-Performance Thread Mills
Victory™ Solid Carbide Thread Mills • Blind and Through Holes
GTM31 • Through Coolant • Metric and Metric Fine
Shank Tolerance
D mm
tolerance h6
6 +0, -0,008
8–10 +0, -0,009
12–18
+0, -0,011
20–30
+0, -0,013
first choice
alternate choice
graWdeUW12UP1V2PV
TiCN
order # catalogue #
D1 size
metric dimensions
D1
D22
DCH
LTHD
LDCH
L
LS
D
cutting
edges
4138545 GTM315001
M4X0.7
3,2 3,3 4,30
7,74
9,59 49 36 6,0
2
4138546 GTM315002
M5X0.8
4,0 4,2 5,30
9,65 11,82 55 36 6,0
2
4138553 GTM315009
M6X0.75
5,1
5,3
6,30 12,07 14,37 62 36 8,0
2
4138547 GTM315003
M6X1
4,8
5,0
6,30
12,06
14,69
62 36 8,0
2
4138554 GTM315010
M8X1
6,8
7,0
8,30
16,09
19,10
74 40 10,0
2
4138548 GTM315004
M8X1.25
6,5
6,8
8,30 15,08 18,42 74 40 10,0
2
4138555 GTM315011
M10X1
8,7 9,0 10,30 20,11 23,52 79 45 12,0
2
4138556 GTM315012
M10X1.25
8,4
8,8 10,30 20,11 23,87
79 45 12,0
2
4138549 GTM315005
M10X1.5
8,2
8,5
10,30
19,59
23,65
79
45 12,0
2
4138557 GTM315013 M12X1.25 10,4 10,8 12,30 23,88 28,00 89 45 14,0
2
4138558 GTM315014
M12X1.5
10,2 10,5 12,30
24,12
28,57
89
45 14,0
2
4138550 GTM315006 M12X1.75 9,9 10,3 12,30 22,86 27,63 89 45 14,0
2
4138559 GTM315015
M14X1.5
12,1 12,5 14,30
27,14
31,98
102 48 16,0
2
4138551 GTM315007
M14X2
11,6 12,0 14,30
28,12
33,62
102 48 16,0
2
4138560 GTM315016
M16X1.5
14,1 14,5 16,30
31,65
36,87
102 48 18,0
2
4138552 GTM315008
M16X2
13,6 14,0 16,30
32,13
38,00
102 48 18,0
2
