High-Performance Thread Mills
Victory™ Solid Carbide Thread Mills • Blind and Through Holes
GTM41 • Through Coolant • Right Hand • Metric and Metric Fine
Shank Tolerance
D mm
tolerance h6
6 +0, -0,008
8–10 +0, -0,009
12–18
+0, -0,011
20–30
+0, -0,013
graWdUe 1W6UPV16PV
TiAlN+MoS2
order # catalogue #
4138576 GTM415001
4138578 GTM415002
4138592 GTM415014
4138580 GTM415003
4138593 GTM415015
4138582 GTM415004
4138594 GTM415016
4138595 GTM415013
4138584 GTM415005
4138586 GTM415006
4138596 GTM415017
4138598 GTM415007
4138587 GTM415008
4138599 GTM415018
4138600 GTM415019
4138588 GTM415009
4138601 GTM415020
4138589 GTM415010
4138602 GTM415021
4138590 GTM415011
4138603 GTM415022
4138591 GTM415012
4138604 GTM415023
4138605 GTM415024
D1 size
M6X1
M7X1
M8X1
M8X1.25
M9X1
M9X1.25
M10X1
M10X1.25
M10X1.5
M11X1.5
M12X1
M12X1.5
M12X1.75
M14X1
M14X1.5
M14X2
M16X1.5
M16X2
M18X1.5
M18X2.5
M20X1.5
M20X2.5
M22X1.5
M24X1.5
D1
4,51
4,51
6,23
6,23
6,23
6,23
6,23
6,23
7,75
7,75
9,15
7,75
9,16
9,15
10,83
11,08
10,83
11,08
14,83
14,38
14,83
14,38
18,23
18,23
first choice
alternate choice
metric dimensions
cutting
D22 L3
L LS D
edges
3,41 16,5 60 36 8,0
3
3,41 16,5 60 36 8,0
3
5,13 21,9 71 40 10,0
4
4,91 21,9 71 40 10,0
4
5,13 21,9 71 40 10,0
4
4,91 21,9 71 40 10,0
4
5,13 21,9 71 40 10,0
4
4,91 21,9 71 40 10,0
4
6,11 26,3 76 40 10,0
4
6,11 26,3 76 40 10,0
4
8,06 30,0 86 45 12,0
4
6,11 26,3 76 40 10,0
4
7,21 32,4 86 45 12,0
4
8,06 30,0 86 45 12,0
4
9,15 37,4 98 48 16,0
4
8,91 41,0 98 48 16,0
4
9,15 37,4 98 48 16,0
4
8,91 41,0 98 48 16,0
4
13,15
47,0
98
48 16,0
4
11,71 51,3 111 50 20,0
5
13,15
47,0
98
48 16,0
4
11,71 51,3 111 50 20,0
5
16,55 56,0 111 50 20,0
5
16,55 56,0 111 50 20,0
5
