M-Style Clamping Cartridges for Negative Inserts
See pages B68–B80
for inserts.
MSSN 45°
order number
catalogue number
D min
F
L1 L1A hS° aO°
gage
insert
right hand
3870336
MSSNR10CA09
40,0 14,0 44 6,1 -13.0 0.0 SN..090308/SN..322
3870335
MSSNR12CA12
50,0 20,0 47 8,3 -13.0 0.0 SN..120408/SN..432
3870334
MSSNR16CA12
60,0 25,0 53 8,3 -13.0 0.0 SN..120408/SN..432
3870333
MSSNR20CA15
70,0 25,0 60 10,3 -13.0 0.0 SN..150612/SN..543
left hand
3870340
MSSNL10CA09
40,0 14,0 44 6,1 -13.0 0.0 SN..090308/SN..322
3870339
MSSNL12CA12
50,0 20,0 47 8,3 -13.0 0.0 SN..120408/SN..432
3870338
MSSNL16CA12
60,0 25,0 53 8,3 -13.0 0.0 SN..120408/SN..432
Spare Parts
lock
D min shim pin hex
40 — KLM33 2 mm
50 — KLM43 2 mm
60 ISSN432 KLM46S 2.5 mm
70 SKSN566K KLM54 2.5 mm
clamp
CKM36
CKM34
CKM36
CKM37
clamp
screw
STCM38
STCM38
STCM9
STCM40
hex
2 mm
2 mm
2.5 mm
2.5 mm
radial
adjusting
screw
KUAM28
KUAM22
KUAM25
KUAM25
hex
2 mm
2 mm
2.5 mm
2.5 mm
axial
adjusting
screw
KUAM30
KUAM31
KUAM32
KUAM32
mounting
screw
191.405
191.406
191.407
191.407
hex washer
4 mm CSWM 060 050
4 mm CSWM 060 050
5 mm CSWM 080 050
5 mm CSWM 080 050
