Victory™ Shoulder Mills • VSM17™ Series
Cylindrical End Mills
Cylindrical End Mills
order number
catalogue number
D1 D
L L2 Ap1 max Z
5988055
VSM17D025Z02A25XD17L110 25 25 110 44
16,3
2
5988056
VSM17D025Z02A25XD17L170 25 25 170 44
16,3
2
5988107
VSM17D032Z02A32XD17L120 32 32 120 50
16,3
2
5988057 VSM17D032Z03A32XD17L120 32 32 120 50 16,3 3
5988109 VSM17D040Z03A32XD17L130 40 32 130 50 16,2 3
5988059 VSM17D040Z04A32XD17L130 40 32 130 50 16,2 4
Spare Parts
max
ramp
angle
8.8
8.8
5.7
5.7
4.0
4.0
coolant
supply
Yes
Yes
Yes
Yes
Yes
Yes
max RPM
41800
41800
34700
34700
29800
29800
kg
0,32
0,54
0,60
0,60
0,77
0,77
insert
screw
191.725
Nm
3,5
NOTE: Standard milling cutters will accept insert nose radii up to 1,6mm without modication.
For tool body modication instructions, see page J16.
wrench
170.025
J22
