Victory™ Shoulder Mills • VSM17™ Series
Cylindrical End Mills • Long Shank
Cylindrical End Mills • Long Shank
order number
catalogue number
D1 D L L2 Ap1 max Z
5988108 VSM17D032Z02A32XD17L210 32 32 210 50 16,3 2
5988058 VSM17D032Z03A32XD17L210 32 32 210 50 16,3 3
5988110 VSM17D040Z03A32XD17L250 40 32 250 50 16,2 3
5988060 VSM17D040Z04A32XD17L250 40 32 250 50 16,2 4
Spare Parts
max
ramp
angle
5.7
5.7
4.0
4.0
coolant
supply
Yes
Yes
Yes
Yes
max RPM
34700
34700
29800
29800
kg
1,14
1,13
1,49
1,49
insert
screw
191.725
Nm
3,5
NOTE: Standard milling cutters will accept insert nose radii up to 1,6mm without modication.
For tool body modication instructions, see page J16.
wrench
170.025
