Victory™ Shoulder Mills • VSM17™ Series
Shell Mills
Shell Mills
order number
catalogue number
D1 D D6 L Ap1 max Z
5988094
VSM17D040Z04S16XD17 40 16 37 40
16,2
4
5988095
VSM17D050Z04S22XD17 50 22 45 40
16,1
4
5988096
VSM17D050Z05S22XD17 50 22 45 40
16,1
5
5988134
VSM17D050Z06S22XD17 50 22 45 40
16,1
6
5988097
VSM17D063Z05S22XD17 63 22 50 40
16,0
5
5988135
VSM17D063Z06S22XD17 63 22 50 40
16,0
6
5988098
VSM17D080Z06S27XD17 80 27 60 50
15,9
6
5988133
VSM17D080Z07S27XD17 80 27 60 50
15,9
7
5988099
VSM17D100Z08S32XD17 100 32 80 50
15,8
8
5988100
VSM17D125Z09S40XD17 125 40 90 63
15,7
9
5988101 VSM17D160Z12S40XD17 160 40 100 63 15,6 12
Spare Parts
max
ramp
angle
4.0
3.0
3.0
3.0
2.1
2.1
1.6
1.6
1.2
0.9
0.7
coolant
supply
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
max RPM
29800
25800
25800
25800
22400
22400
19500
19500
17200
15200
13300
kg
0,19
0,28
0,29
0,28
0,45
0,45
0,98
0,96
1,63
2,94
3,66
insert
socket-head socket-head cap screw
D1 screw
Nm
wrench
cap screw
with coolant groove
40,0 191.725
3,5
170.025
MS1294
MS1294CG
50,0 191.725
3,5
170.025
MS1234
MS1294CG
50,0 191.725
3,5
170.025
MS1234
MS1234CG
63,0 191.725
3,5
170.025
MS1234
MS1234CG
80,0 191.725
3,5
170.025
MS2038
MS2038CG
100,0 191.725
3,5
170.025
–
–
125,0 191.725
3,5
170.025
–
–
160,0 191.725
3,5
170.025
–
–
NOTE: Standard milling cutters will accept insert nose radii up to 1,6mm without modication.
For tool body modication instructions, see page J16.
coolant lock
screw assembly
–
–
–
–
–
MS2195C
MS2187C
–
coolant
lock screw
–
–
–
–
–
–
–
12146107000
coolant
cap
–
–
–
–
–
–
–
J24
