Victory™ Shoulder Mills • VSM17™ Series
Inserts
Insert Selection Guide
Material
Group
P1–P2
P3–P4
P5–P6
M1–M2
M3
K1–K2
K3
N1–N2
N3
S1–S2
S3
S4
H1
Light
Machining
Geometry
Grade
.E..ML
WP40PM
.E..ML
WP35CM
.E..ML
WP35CM
.E..ML
WP25PM
.E..ML
WP35CM
.S..MM
WK15CM
.E..ML
WP35CM
.F..ALP
WN10HM
––
.S..MM
WP25PM
.S..MM
WU35PM
.S..MM
WP25PM
––
General
Purpose
Geometry
Grade
.S..MM
WP40PM
.S..MM
WP35CM
.S..MM
WU35PM
.S..MM
WP25PM
.S..MM
WP35CM
.S..MM
WK15CM
.S..MM
WP35CM
.F..ALP
WN25PM
––
.S..MM
WU35PM
.S..MM
WU35PM
.S..MM
WU35PM
––
Heavy
Machining
Geometry
Grade
.S..MH
WP40PM
.S..MH
WP35CM
.S..MH
WP35CM
.S..MM
WU35PM
.S..MH
WP35CM
.S..MH
WK15CM
.S..MH
WP35CM
.F..ALP
WN25PM
––
.S..MM
WU35PM
.S..MM
WU35PM
.S..MM
WU35PM
––
XDCT-ML
XDCT-ML
first choice
alternate choice
P
M
K
N
S
H
cutting
catalogue number
edges
L1
BS
S
W R
XDCT170404PEERML 2 19,15 2,62 4,90 9,60 0,40
XDCT170408PEERML 2 19,15 2,22 4,90 9,60 0,80
XDCT170412PEERML 2 19,16 1,82 4,90 9,60 1,20
XDCT170416PEERML 2 19,17 1,42 4,90 9,60 1,60
XDCT170420PEERML 2 19,17 1,01 4,90 9,60 2,00
XDCT170424PEERML 2 19,17 0,63 4,90 9,60 2,40
XDCT170432PEERML 2 18,85 — 4,88 9,59 3,20
XDCT170440PEERML 2 18,33 — 4,87 9,59 4,00
