Victory™ Shoulder Mills • VSM490™-15 Series
Indexable Inserts
XNGU-MM
XNPU-MM
XNGU-ML
XNPU-ML
XNGU-MH
• -ML geometry is the first choice for machining stainless
steel. With reduced cutting forces, this is recommended
for improved wall finishing capabilities in steels.
• -MM is the universal geometry for VSM490-15.
First choice when machining steel, as well as stainless
steel and high-temp alloys in heavy applications.
• -MH geometry is the first choice for cast iron machining
in the medium and heavy applications.
XNGU-MM • Precision Finishing
Back View
first choice
alternate choice
P
M
K
N
S
H
catalogue number
XNGU15T604SRMM
cutting
edges
4
XNGU15T608SRMM
4
XNPU-ML • Utility Roughing
L1 S W BS R hm
16,20 6,88 10,00 2,20 0,40 0,10
16,20 6,88 10,00 1,90 0,80 0,10
catalogue number
XNPU15T608ERML
cutting
edges
4
XNPU-MM • Utility Roughing
L1 S W BS R hm
16,10 6,88 10,00 1,90 0,80 0,08
catalogue number
XNPU15T608SRMM
cutting
edges
4
XNPU15T612SRMM
4
XNPU15T616SRMM
4
XNGU-MH • Utility Roughing
L1 S W BS R hm
16,10 6,88 10,00 1,90 0,80 0,10
16,10 6,88 10,00 1,50 1,20 0,10
16,10 6,88 10,00 1,10 1,60 0,10
catalogue number
XNGU15T608SRMH
XNGU15T616SRMH
cutting
edges
4
4
L1 S W BS
16,20 6,88 10,00 1,80
16,20 6,88 10,00 1,00
R
0,80
1,60
