Victory™ Shoulder Mills • VSM490™-15 Series
Inserts
Insert Selection Guide
Material
Group
P1–P2
P3–P4
P5–P6
M1–M2
M3
K1–K2
K3
N1–N2
N3
S1–S2
S3
S4
H1
Light
Machining
Geometry
Grade
XNGU-ML
WP40PM
XNGU-ML
WP25PM
XNGU-MM
WP25PM
XNGU-ML
WP25PM
XNGU-ML
WP25PM
XNGU-MH
WK15CM
XNGU-MH
WK15PM
––
––
XNGU-ML
WP25PM
XNGU-ML
WP25PM
XNGU-ML
WU35PM
––
General
Purpose
Geometry
Grade
XNPU-ML
WP40PM
XNPU-MM
WP35CM
XNPU-MM
WP35CM
XNGU-ML
WU35PM
XNGU-ML
WU35PM
XNGU-MH
WK15CM
XNGU-MH
WK15PM
––
––
XNGU-ML
WU35PM
XNGU-ML
WU35PM
XNGU-ML
WU35PM
––
Heavy
Machining
Geometry
Grade
XNPU-MM
WP40PM
XNPU-MM
WP40PM
XNPU-MM
WP35CM
XNGU-MM
WU35PM
XNGU-MM
WU35PM
XNGU-MH
WP35CM
XNGU-MH
WP40PM
––
––
XNGU-MM
WU35PM
XNGU-MM
WU35PM
XNPU-MM
WU35PM
––
XNGU-ML
XNGU-ML
• -ML geometry is the first choice for machining stainless
steel. With reduced cutting forces, this is recommended
for improved wall finishing capabilities in steels.
XNGU-ML • Precision Finishing
Back View
first choice
alternate choice
P
M
K
N
S
H
catalogue number
XNGU15T604ERML
XNGU15T608ERML
cutting
edges
4
4
L1 S W BS R hm
16,20 6,88 10,00 2,20 0,40 0,08
16,20 6,88 10,00 1,80 0,80 0,08
J36
