WIDIA - Полный каталог инструмента - 2017
• WK12PG TiCN for
cast iron.
для размещения заказа - zakaz@widiahanita.ru
High-Performance Taps
Victory™ Solid Carbide Straight-Flute Taps • Blind Holes
Shank Tolerance
D mm
tolerance h6
6 +0, -0,008
8–10 +0, -0,009
12–16
+0, -0,011
GX50 • Form C Semi-Bottoming Chamfer • Through Coolant M6 and Larger • Metric • For Cast Iron
gradWeKW12KP1G2PG
TiCN
order # catalogue #
5520817 GX505004
5520818 GX505005
5520819 GX505006
5520820 GX505008
5520822 GX505010
5520823 GX505012
5520824 GX505014
D1 size
M4 X 0,7
M5 X 0,8
M6 X 1
M8 X 1,25
M10 X 1,5
M12 X 1,75
M14 X 2
first choice
alternate choice
metric dimensions
number
class
L
L3 L2
D
of utes
of t
63 10 21 4,5 3 6HX
70 10 25 6,0 3 6HX
80 10 30 6,0 4 6HX
90 13 35 8,0 4 6HX
100 15 39 10,0
4
6HX
110 18 44
9,0
4
6HX
110 20 52 11,0
4
6HX
zakaz@widiahanita.ru
www.widiahanita.ru
Y51
